Product List ʦ੡඼Ұཡʧ

Lamp Type LED

ʢT A=25ˆʣ
৭౓࠲ඪ ޫ౓ ޫଋ ॱిѹ ࢦ޲ಛੑ ٯిྲྀ ઈର࠷େఆ֨ Absolute Maximum Ratings ࠷େࠝแ਺ྔ ˞
ύοέʔδ ඼໊ Chromaticity Coordinate Śv Пv V F Directivity Ś F Ś R V R (pcs.) ࣮૷ํ๏ ੡඼༻్ྫ
Target
Package Product Type Typ. Typ. Typ. Typ. Max. 2В 1/2 (mA) Max. (V) Ś F Ś FP ˞ V R Ś R P D T opr T stg Qty./Pack Mounting
(x,y) (cd) (lm) (V) (V) (degree) (ЖA) (mA) (mA) (V) (mA) (mW) ( ˆ ) ( ˆ ) (Max.) Application
Φ5 Type

NSDW510GS-K1 0.310 0.320 - 25.5 3.4 3.7 35 70 100 5 80 200 5 - 296
-30 ʙ +85 -40 ʙ +100
NSDL510GS-K1 0.410 0.390 - 21 3.4 3.7 35 70 100 5 80 200 5 - 296 ϑϩʔ
2500/P Flow
NSDW570GS-K1 0.310 0.320 - 28 3.4 3.7 140 70 100 5 80 200 5 - 296
-30 ʙ +85 -40 ʙ +100
NSDL570GS-K1 0.410 0.390 - 23 3.4 3.7 140 70 100 5 80 200 5 - 296 Specialty Lighting

NSPW500GS-K1 33 - 3.1 3.5 15 20 50 5 30 100 5 - 105
0.310 0.320
Specialty Lighting
NSPW500DS 27 - 3.2 3.5 15 20 50 5 30 100 5 - 105 -30ʙ+85 -40ʙ+100
NSPL500DS 0.410 0.390 22 - 3.2 3.5 15 20 50 5 30 100 5 - 105
NSPW510HS-K1 0.344 0.355 13.8 - 2.8 3.1 30 20 50 5 40 120 5 - 124
NSPW510DS-D1 0.310 0.320 12.2 - 3.2 3.5 30 20 50 5 30 100 5 - 105
-30ʙ+85 -40ʙ+100
NSPW510DS 0.310 0.320 6.15 - 3.2 3.5 45 20 50 5 30 100 5 - 105 ϑϩʔ
2500/P Flow
NSPL510DS 0.410 0.390 4.7 - 3.2 3.5 50 20 50 5 30 100 5 - 105
NSPW570GS-K1 1.9 - 3.1 3.5 130 20 50 5 30 100 5 - 105
0.310 0.320
NSPW570DS 1.7 - 3.2 3.5 120 20 50 5 30 100 5 - 105 -30ʙ+85 -40ʙ+100
NSPL570DS 0.410 0.390 1.2 - 3.2 3.5 130 20 50 5 30 100 5 - 105
NSPW515DS 0.310 0.320 2.3 - 3.2 3.5 65 20 50 5 30 100 5 - 105
-30ʙ+85 -40ʙ+100
NSPL515DS 0.410 0.390 1.9 - 3.2 3.5 70 20 50 5 30 100 5 - 105

Φ3 Type
NSPW300DS 12.9 - 3.2 3.5 20 20 50 5 30 100 5 - 105 ϑϩʔ
0.310 0.320 -30ʙ+85 -40ʙ+100 4000/P Flow
NSPW310DS 6.2 - 3.2 3.5 50 20 50 5 30 100 5 - 105
Flat Type

ϑϩʔ
NSPWF50DS 0.310 0.320 1.2 - 3.2 3.5 130/120 20 50 5 30 100 5 - 105 -30ʙ+85 -40ʙ+100 4000/P Flow
